Technical data
- Rated input power: 2,400 W
- Cutting disc diameter: 355 mm
- Cutting disc bore: 25.4 mm
- No-load speed: 3,800 rpm
- Cutting capacity at rectangle 0º: 100 x 196 mm
- Cutting capacity at square 0º: 119 x 119 mm
- Cutting capacity at L-profile 0º: 130 x 130 mm
- Weight: 18.1 kg
- Cutting capacity at rectangle 45º mitre: 107 x 115 mm
- Cutting capacity at square 45º mitre: 110 x 110 mm
- Cutting capacity at L-profile 45º mitre: 115 x 115 mm
- Tool dimensions (width x length x height): 256 x 520 x 400 mm
Noise/vibration information
- Sound pressure level: 100.5 dB(A)
- Sound power level: 113 dB(A)
- Uncertainty K: 3 dB
