Technical data
- Rated input power: 600 W
- No-load speed: 30,000 rpm
- Voltage, electrical: 240 V
- Spindle collar diameter: 43 mm
- Weight: 1.4 kg
- Max. grinding tool diameter: 50 mm
- Power output: 350 W
- Max. collet diameter: 8
- Spanner size of locking nut: 19 mm
- Spanner size of grinding spindle: 19 mm
- Switch: Lockable Switch
- Total vibration values (Surface grinding up to diameter of 25):
- Vibration emission value ah: 3 m/s²
- Uncertainty K: 1.5 m/s²
- Total vibration values (Surface grinding up to diameter of 50):
- Vibration emission value ah: 8 m/s²
- Uncertainty K: 1.5 m/s²
- Noise/vibration information:
- Sound pressure level: 89 dB(A)
- Sound power level: 100 dB(A)
- Uncertainty K: 3 dB
- Surface grinding up to diameter of 25:
- Vibration emission value ah: 3 m/s²
- Uncertainty K: 1.5 m/s²
- Surface grinding up to diameter of 50:
- Vibration emission value ah: 8 m/s²
- Uncertainty K: 1.5 m/s²
Included In
-
Voltage 240 V
-
Collet with locking nut 6 mm (Order number: 2 608 570 137)
-
Single-ended open-jaw spanner (Order number: 1 607 950 525)
