Technical data
- Cutting capacity in steel (400 N/mm²), max.: 2 mm
- No-load stroke rate: 2,400 spm
- Material that can be processed: Steel up to 400 N/mm² at 2.0 mm
- Cutting track width: 6 mm
- Pre-drilling for interior cut-outs: 16 mm
- Smallest radius: 3 mm
- Stroke rate under load: 1,500 spm
- Weight: 2.1 kg
- Cutting capacity in steel (600 N/mm²), max.: 1.4 mm
- Cutting capacity in steel (800 N/mm²), max.: 1 mm
- Cutting capacity in aluminium (200 N/mm²), max.: 2.5 mm
- Electric specifications:
- Rated input power: 500 W
- Power output: 270 W
- Noise/vibration information
- Sound pressure level: 86 dB(A)
- Sound power level: 97 dB(A)
- Uncertainty K: 3 dB
- Total vibration values:
- Vibration emission value ah: 9 m/s²
- Uncertainty K: 1.5 m/s²
Included in
-
Die plate (Order number: 2 608 639 900)
-
Hex key WAF 2.5 (spare part number 1 907 950 003)
-
Punch (Order number: 2 608 639 013)
