Drilling & Fastening Capacities
-
- Siding Board Capacity: 170 mm (6-11/16”)
- Wood Capacity (Auger-Bit): 50 mm (2”)
- Masonry Capacity: 16 mm (5/8”)
- Steel Capacity: 13 mm (1/2”)
- Chuck Capacity: 1.5 – 13 mm (1/16 – 1/2”)
Torque Output
-
- Max Fastening Torque (Hard Joint): 130 N·m
- Max Fastening Torque (Soft Joint): 65 N·m
- Max Lock Torque: 125 N·m (1,100 in.lbs.)
Speed & Impact Performance
-
- No Load Speed (High): 0 – 2,100 RPM
- No Load Speed (Low): 0 – 550 RPM
- Impacts Per Minute (High): 0 – 31,500 IPM
- Impacts Per Minute (Low): 0 – 8,250 IPM
Physical Specifications
-
- Dimensions (L x W x H): 178 x 81 x 265 mm (measured with BL1830B / BL1850B / BL1860B batteries)
- Net Weight: 2.3 – 2.7 kg (5.1 – 6.0 lbs.)
