Technical Specifications
- Max blade opening width: 50 mm (2″)
- Max cable cutting capacity: 600V-CV: 500mm² single-core (38mm (1-1/2))
- 6600V-CV: 500mm² single-core (45mm (1-3/4))
- 600V-IV: 500mm² single-core (35mm (1-3/8))
- 600V-VVR: 150mm² triple-core (47mm (1-7/8))
- Dimensions (L x W x H): w/ BL1830B / BL1840B / BL1850B / BL1860B: 116 x 197 x 363 mm (4-9/16 x 7-3/4 x 14-1/4″)
- Net weight: 2.9 kg (6.4 lbs.)
