Technical Specifications
- Fastening Capacities: Standard bolt: M27 – M45 (1-1/8 – 1-7/8″)
- High strength bolt: M20 – M33 (3/4 – 1-3/8″)
- Square Drive: 25.4 mm (1″)
- No Load Speed (rpm): Max / Hard / Med. / Soft: 0 – 1,200 / 0 – 850 / 0 – 700 / 0 – 600 minˉ¹
- Impacts Per Minute (IPM): Max / Hard / Med. / Soft: 0 – 1,750 / 0 – 1,500 / 0 – 1,300 / 0 – 1,200
- Max. fastening torque: 3,150 N·m (2,323 ft.lbs.)
- Dimensions (L x W x H): w/ BL4050F: 435 x 135 x 297 mm (17-1/8 x 5-5/16 x 11-3/4″)
- Net weight: 10.8 – 11.8 kg (23.8 – 26.0 lbs.)
