Technical Specifications
- Capacity: Standard bolt : M10 – M20 (3/8″ – 3/4″)
- High Tensile bolt : M10 – M16 (3/8″ – 5/8″)
- Square drive: 12.7mm (1/2″)
- No Load Speed (rpm): Hard / Medium / Soft: 0 – 3,200/0 – 2,600/0 – 1,800/0 – 1,000
- Impacts Per Minute (IPM): Hard / Medium / Soft: 0 – 4,000/0 – 3,400/0 – 2,600/0 – 1,800
- Max tightening torque: 330 N·m (240 ft.lbs.)
- Dimensions (L x W x H): 144 x 81 x 246 mm
- Net weight: 1.5 – 1.8 kg (3.4 – 4.1 lbs.)
