Technical Specifications
- Wheel Diameter: 255, 260 mm (10, 10-1/4″)
- Hole diameter: 15.88, 25.4, 30 mm (5/8, 1, 1-3/16″)
- Bevel range: 0° – Left : 45°
- Miter range: Left: 45 ° / Right: 52 °
- Cutting capacity: Bevel 0° / Miter 0°: 69 x 130 mm (2-3/4 x 5-1/8″), 93 x 95 mm (3-5/8 x 3-3/4″)
- Bevel 0° / Miter 45°LR: 69 x 85 mm (2-3/4 x 3-3/8″), 93 x 67 mm (3-5/8 x 2-5/8″)
- Bevel 45°L / Miter 0°: 35 x 130 mm (1-3/8 x 5-1/8″), 53 x 95 mm (2-1/16 x 3-3/4″)
- Bevel 45°L / Miter 45°L: 35 x 65 mm (1-3/8 x 2-9/16″), 49 x 42 mm (1-15/16 x 1-5/8″)
- Bevel 45°L / Miter 45°R: 35 x 91 mm (1-3/8 x 3-5/8″), 49 x 67 mm (1-15/16 x 2-5/8″)
- No load speed (rpm): 4,300 minˉ¹
- Dimensions: 545 x 476 x 585 mm (21-1/2 x 18-3/4 x 23″)
- Net weight 14.8 – 16.0 kg (32.6 – 35.3 lbs.)
